DURMA PRESS BRAKE 12' X 320 TON NEW 2012

Tonnage
320 T
Type
HYD
OA Length
159 "
BH
142 "
Stroke
14.37 "
# Axis
5
Dimensions
209" X 75" X 127"
Weight
45745 LBS
Control
CNC (DELEM 66 T)
DURMA PRESS BRAKE SYNCRO AD-R -40320
3 AXIS : Y1-Y2 AND X S/N: 73661612257
FOURTH AXIS ' R '
MAXIMUM BENDING CAPACITY:160" X 320 TONS (4050 MM X 320 TONS)
BACK GAUGE WITH 650 MM TRAVEL
DISTANCE BETWEEN COLUMNS: 142" ( 3600 MM )
FAST APPROACH SPEED :3,94"/SEC) ( 180 MM/SEC )
BENDING SPEED:0,39" / SEC) ( 10 MM/SEC )
RETURN SPEED:3,94" / SEC ( 100 MM/SEC )
EUROPEAN/AMER. CLAMPING SYSTEM FOR TOP TOOL
4 WAY MULTI-VEE BOTTOM DIE EUROPEAN M460-R-2009
WITH OPENING OF : 22-35-16-50 MM
EUROPEAN STYLE TOP TOOL MODEL DURM135-75-R08-105
CNC CROWING SYSTEM
DAYLIGHT: 24,80" ( 630 MM )
TABLE WIDHT:6,06" ( 154 MM )
TABLE HEIGHT:35,43" ( 900 MM )
STROKE:14,37" ( 365 MM )
THROAT DEPTH: 16,14" ( 410 MM )
SUPPORT ARMS:2
BACK GAUGE FINGERS:2
FIESSLER SAFETY SYSTEM AKAS II
SECOND ELECTRIC PEDAL
SPEED OF TRAVEL IN ' X ' AXIS:19,69"/SEC ( 500 MM/SEC )
MOTOR:37 KW VOLTAGE 575/3/60
OIL TANK:250 LITERS
MACHINE DIMENSIONS:209" X 75" X 127" X 45745 LBS
5300 MM X 1910 MM X 3230 MM X 20750 KGS

66T DELEM CONTROL
